General

• High Dynamic Range (HDR) Frontview Image
• Video Signal (NTSC) Output
• Multi View Angle Selection: Panorama View [Panorama], Ground View [Top], Corner View [Corner]

Camera

• Normal Image Output
• Colour CMOS Image Sensor
• Automatic Exposure Adjustment
• Automatic White Balance Adjustment
• Internal Synchronisation

Dimensions

• Camera: 23.6 x 23.6 x 26.1mm (excluding projection on the rear)
• Camera Cable Length: 1m
• Camera Extension Cable Length: 3m

General

• Power Requirement: 6.0V DC (5.0 to 9.0VDC allowable)
• Ground Type: Negative Ground
• Max. Power Consumption: 1.2W (6.0V)

Camera

• Output Image: Normal image, CVBS (NTSC Video signal), for 16:9 wide-screen
• Image Output Impedance: 75 Ohms (1Vp-p)
• Image Sensor: 1/4″ Type Color CMOS Image Sensor, Aspect Ratio 16:9
• Effective Number of Pixels: 1280 (horizontal) x 720 (vertical) approximately 1.2 Mega pixels
• Lens: Focal Length: f=1.27mm
• Lens: Brightness: F=1:1.8
• Angle of Field: Horizontal = 180° , Vertical = 70°
• S/N Ratio: 41 dB or more
• Resolution (Horizontal. Center Area): 330 TV Lines
• Operating Temperature: -30°C – +70°C
• Illumination Range: Approximatly 1.5Lx to 100kLx
• Weight: 41g (including cable but not including bracket and screw)
