• Hi-Res Audio DSP Amplifier (192kHz / 32bit max sampling rate without down-sampling)
• Built-in 12-channel amplifier (8x 50 Watts + 4x 80 Watts @ 4Ω, 14,4V)
• MUSES 8820 operational amplifier
• Highly flexible system configuration
• Matrix input summing
• High-Class XO (1/1.000) Crystal Oscillator Clock Generator
• 31-Band / Channel Parametric / Graphic Equalizer
• Digital Time Correction
• External Bluetooth dongle included
• High-performance PC software
• Optional controller available (RUX-C810)

Performance

• Power Output (rated 4Ω, 14,4V, 10% THD): 8x 50 Watt + 4x 80 Watt
• THD+N RCA: 1W into 4Ω ≤0.01%
• S/N RCA: A-wt ≥100dB
• Input Voltage: High level 26 Vpp / RCA 8 Vpp
• Output Voltage: High level CH1～8: 40 Vpp, CH9～12: 50 Vpp / RCA 10 Vpp
• Frequency Response (1W into 4Ω): 20Hz～40kHz

General

• Input Impedance: High level 14Ω / RCA 10kΩ
• System Sampling Rate: 192kHz/32bit
• Operating Voltage: 9～16V
• Standby Power Consumption: ≤0.1W
• Remote Start Input High-Level (H1-/H1+), ACC optional
• Remote Start Output: 12V (0.2A)
• Output Channel Signal Gain Range: -60dB～+6dB
• Output Signal Equalizer
  Type: Parametric / Graphic Equalizer
  Frequency: 20Hz～40kHz (1Hz steps)
  Q value: 0.404～28.852
  Gain: -12.0dB～+12.0dB (0.1dB steps)
• Output Signal Divider
  Pass independent filters
  Filter type: Link-Ril, Bessel, Butter-W
  Filter crossover point: 20Hz～40kHz (1Hz steps)
  Filter slope: -6dB/Oct～-48dB/Oct
• Output Phase: normal phase or reverse phase (0°～360°)
• Output Delay: 0.000～20.000ms、0～692cm、0～273inch
• Preset Sound Effects: 6 sound data presets
• Weight 4.5kg
• Dimensions: Width 278mm / Depth 256mm / Height 58mm
