• Alpine’s Class D amplifier circuit with Dynamic Peak Power (D.P.P.)
• Compact size
• 4-channel Amplifier
• Weather resistant (IP66 rating)
• 150W x 4 D.P.P. (2Ω/4Ω, 14.4V, ≤ 1% THD+N)
• CTA-2006-B Specifications: 75W RMS x 4 (2Ω/4Ω, 14.4V, ≤ 1% THD+N)
• 82dB S/N (ref. 1W into 4Ω)
• >0.05% THD
• Hi Resolution Audio Ready
• OEM-grade Tyco 26-pin connector with pigtail wire harness
• Speaker/RCA inputs (Selectable, High range=0.5-10V, Low range=0.2-4V)

Crossover

• Crossovers: Off/HP/LP, Fc=50-400Hz @ -12dB/Oct. (variable)
• Input gain settings (variable)
• 2ch/4ch input (selectable)

Dimensions

• Width: 9-3/16”
• Height: 1-5/8”
• Depth: 3-3/4”
