Woofer

• 6.5″ (165mm) Lightweight Glass Fiber Composite Component Speaker
• HAMR (High Amplitude Multi-Roll) Surround
• Large 35mm Voice Coil
• Magnet Material: Strontium Ferrite
• Grill sold separately: KTE-S65G

Tweeter

• 1″ Extended-Range Soft Dome
• Magnet Material: Ferrite
• Application Type: External/Swivel Tweeter Mounting Kit
• Flush mount and Collapsable for OEM fit.
• Grill: Perforated Net

Crossover Network

• Woofer: Copper Air-Coiled Wound Inductor
• Tweeter: High Quality Audio-Grade Polycap

Power Handling

• Peak Power: 240 Watts
• RMS Power: 80 Watts (CTA-2031 Compliant)

Dimensions Woofer

• Frame 165 mm
• Cutout Diameter: 129mm
• Mounting Depth: 57.7 mm
• Mounting Height: 12.0 mm
• Magnet: 90.0 mm

Dimensions Tweeter

• Frame: 58mm
• Mounting Diameter: 51mm
• Mounting Depth: 17.6mm
• Height: 25.6 mm

General

• Frequency Range: 55 Hz – 40 kHz
• Impedance: 4 Ohms
• Sensitivity: 88 dB/W
• Recommended Amplification: up to 80W RMS per channel
